8XD Internal Coolant Drills

  • Ultra-Deep Hole Capacity: Features a 12xD Depth-to-Diameter Ratio, specifically designed for precision drilling of extra-deep holes in a single, stable operation.
  • Advanced Through-Coolant: Engineered with Two Internal Coolant Holes to deliver high-pressure fluid directly to the tip, ensuring instant cooling and powerful chip ejection.
  • Maximum Rigidity: Made from premium sub-micron grain carbide to ensure exceptional hole straightness and dimensional accuracy even at extreme depths.
  • Massive Spec Selection: Full range of precision diameters from 4.0mm to 20.0mm, meeting the most demanding industrial and aerospace requirements.
Categories:
Learn More
Download PDF
Description
  • Ultra-Deep Hole Capacity: Features a 12xD Depth-to-Diameter Ratio, specifically designed for precision drilling of extra-deep holes in a single, stable operation.
  • Advanced Through-Coolant: Engineered with Two Internal Coolant Holes to deliver high-pressure fluid directly to the tip, ensuring instant cooling and powerful chip ejection.
  • Maximum Rigidity: Made from premium sub-micron grain carbide to ensure exceptional hole straightness and dimensional accuracy even at extreme depths.
  • Massive Spec Selection: Full range of precision diameters from 4.0mm to 20.0mm, meeting the most demanding industrial and aerospace requirements.

订货号 Order Number 规格 Specification 刀径 D 刃长 L1 柄径 D1 总长 L 柄长 LS
ICD-12D-0040 D4*64H*D4*102L 4 64 4 102 36
ICD-12D-0045 D4.5*64H*D6*102L 4.5 64 6 102 36
ICD-12D-0050 D5.0*80H*D6*118L 5 80 6 118 36
ICD-12D-0055 D5.5*80H*D6*118L 5.5 80 6 118 36
ICD-12D-0060 D6.0*80H*D6*118L 6 80 6 118 36
ICD-12D-0065 D6.5*108H*D7*146L 6.5 108 7 146 36
ICD-12D-0070 D7.0*108H*D8*146L 7 108 8 146 36
ICD-12D-0075 D7.5*108H*D8*146L 7.5 108 8 146 36
ICD-12D-0080 D8.0*120H*D8*162L 8 120 8 162 36
ICD-12D-0085 D8.5*120H*D10*162L 8.5 120 10 162 40
ICD-12D-0090 D9.0*120H*D10*162L 9 120 10 162 40
ICD-12D-0095 D9.5*120H*D10*162L 9.5 120 10 162 40
ICD-12D-0100 D10.0*120H*D10*162L 10 120 10 162 45
ICD-12D-0105 D10.5*156H*D12*204L 10.5 156 12 204 45
ICD-12D-0110 D11.0*156H*D12*204L 11 156 12 204 45
ICD-12D-0115 D11.5*156H*D12*204L 11.5 156 12 204 45
ICD-12D-0120 D12.0*156H*D12*204L 12 156 12 204 45
ICD-12D-0125 D12.5*182H*D14*230L 12.5 182 14 230 45
ICD-12D-0130 D13.0*182H*D14*230L 13 182 14 230 45
ICD-12D-0135 D13.5*182H*D14*230L 13.5 182 14 230 45
ICD-12D-0140 D14.0*182H*D14*230L 14 182 14 230 45
ICD-12D-0145 D14.5*208H*D16*260L 14.5 208 16 260 48
ICD-12D-0150 D15.0*208H*D16*260L 15 208 16 260 48
ICD-12D-0155 D15.5*208H*D16*260L 15.5 208 16 260 48
ICD-12D-0160 D16.0*208H*D16*260L 16 208 16 260 48
ICD-12D-0165 D16.5*234H*D18*285L 16.5 234 18 285 48
ICD-12D-0170 D17.0*234H*D18*285L 17 234 18 285 48
ICD-12D-0175 D17.5*234H*D18*285L 17.5 234 18 285 48
ICD-12D-0180 D18.0*234H*D18*285L 18 234 18 285 48
ICD-12D-0185 D18.5*258H*D20*310L 18.5 258 20 310 50
ICD-12D-0190 D19.0*258H*D20*310L 19 258 20 310 50
ICD-12D-0195 D19.5*258H*D20*310L 19.5 258 20 310 50
ICD-12D-0200 D20.0*258H*D20*310L 20 258 20 310 50
