CVKT0502R-HF

ZANHO CVKT0502R-HF series: High-efficiency high feed milling inserts engineered for extreme metal removal rates. Featuring a large positive rake angle and a unique V-shaped bottom positioning structure, these inserts ensure maximum clamping rigidity and stability. Ideal for face milling, profiling, ramping, and helical interpolation, they are perfectly matched with LV05 series coolant-through tool holders for superior chip evacuation and heat control.
Categories:
Learn More
Download PDF
Description

Technical Features

  • HF High Feed Geometry: Optimized for high-speed machining and maximum material removal rates.
  • Large Positive Rake Angle: Reduces cutting forces and minimizes power consumption.
  • V-Shaped Bottom Positioning: Enhances clamping rigidity and prevents insert movement under heavy loads.
  • Multifunctional Performance: Suitable for face milling, profiling, ramping, and helical interpolation.
  • Coolant-Through Compatibility: Optimized for LV05 holders with internal coolant for superior chip evacuation.

CVKT0502R-HF Insert Specifications (mm)

Parameter Value Parameter Value
INSL (Length) 5.60 ap (max) Actual 0.40
W1 (Width) 4.10 ap (min) 0.20
S (Thickness) 2.50 fz (min) 0.30 mm/t
APMX (Theoretical) 0.50 fz (max) 0.70 mm/t

LV05 Matching Tool Holders

Internal Coolant (SKD61) External Coolant
LV05-C8-08-100-2T-N-SKD61 LV05-C8-08-100-2T
LV05-C10-10-100-3T-N-SKD61 LV05-C10-10-100-3T
LV05-C10-11-100-3T-N-SKD61 LV05-C10-11-100-3T
LV05-C12-12-100-4T-N-SKD61 LV05-C12-12-100-4T
LV05-C12-13-100-4T-N-SKD61 LV05-C12-13-100-4T
LV05-C14-14-120-5T-N-SKD61 LV05-C14-14-120-5T
LV05-C16-16-150-5T-N-SKD61 LV05-C16-16-150-5T
LV05-C16-17-150-5T-N-SKD61 LV05-C16-17-150-5T
